Product Features:

· Wide range of applicable flow meters and fluid media

· Automatic conversion of flow units and automatic calculation of flow coefficients for differential pressure flow meters

· Steam density is calculated based on the IAPWS-IF97 formula, with automatic identification of superheated and saturated steam states

· Emergency fault tolerance function: Compensatory calculation using emergency parameter values when temperature or pressure signals are abnormal

· Debugging and calculation function: View raw transmitter/sensor signal values and intermediate parameters of flow calculation

· Audit record: Power failure recording function

· Alarm list: Supports recording alarm information of instantaneous or accumulated values such as flow rate, temperature, pressure, differential pressure/frequency/volume/mass

· Accumulation report: Supports shift, daily, monthly and yearly reports of accumulated flow

· Communication function: Compliant with standard Modbus RTU protocol, supporting RS485 and RS232C communication interfaces

Standard Modbus TCP protocol supports Ethernet RJ45 interface

· Transmission function: Supports standard current transmission output with selectable signal source channels

· Report backup function: Supports backup of all accumulation reports

· Import and export function: Supports import and export of instrument configuration parameters

· Timed printing function: Supports timed printing of data including flow rate, temperature, pressure and accumulation values

Non-standard Customization Support:

· Supports OEM faceplate customization and boot interface customization

· Supports customization of flow algorithms and operation interfaces

· Supports customization of signal types and technical parameters

· Supports customization of F-LINK management system

Installation Methods:

Installation Method:

· Step 1: Push the instrument forward into the mounting hole from the front of the mounting panel (steel plate is required). The thickness of the mounting panel is (1.5~6.5) mm.

· Step 2: Install the mounting brackets supplied with the instrument as shown in the figure above (install one bracket on each of the left and right sides of the instrument; M4 standard screws shall be used for the instrument mounting brackets).

· Step 3: After the main body of the instrument is installed, connect the signal lines and power lines.
